G5PA-28-MC DC12 BY OMZ (PF)
RELAY GEN PURPOSE DPST 5A 12VManufacturer: Omron Electronics Inc-EMC Div
Categories: Power Relays, Over 2 Amps
Quality Control: Learn More
General Purpose Relay DPST-NO (2 Form A) 12VDC Coil Through Hole
Additional Information
Series: G5PA-2RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Operating Temperature | -25°C ~ 70°C |
| Termination Style | PC Pin |
| Approval Agency | CSA, EN, SEMKO, TUV |
| Relay Type | General Purpose |
| Coil Current | 44.2 mA |
| Coil Type | Non Latching |
| Seal Rating | Sealed - Flux Protection |
| Contact Material | - |
| Contact Form | DPST-NO (2 Form A) |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 24VDC - Max |
| Must Release Voltage | 1.2 VDC |
| Must Operate Voltage | 8.4 VDC |
| Operate Time | 15 ms |
| Release Time | 5 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | 1250VA, 120W |
