MKS3P5DC24
MKS RELAYManufacturer: Omron Automation and Safety
Categories: Power Relays, Over 2 Amps
Quality Control: Learn More
General Purpose Relay 3PDT (3 Form C) 24VDC Coil Socketable
Additional Information
Series: MKSRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Mechanical Indicator |
| Packaging | Bulk |
| Mounting Type | Socketable |
| Coil Voltage | 24VDC |
| Operating Temperature | -40°C ~ 60°C |
| Termination Style | Plug In, 11 Pin (Octal) |
| Relay Type | General Purpose |
| Coil Current | 55.8 mA |
| Coil Type | Non Latching |
| Seal Rating | - |
| Contact Material | Silver Tin Indium (AgSnIn) |
| Contact Form | 3PDT (3 Form C) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 250VAC, 30VDC - Max |
| Must Release Voltage | 3.6 VDC |
| Must Operate Voltage | 19.2 VDC |
| Operate Time | 30 ms |
| Release Time | 20 ms |
| Coil Insulation | - |
Request a Quote
