MK2KP AC12
RELAY GEN PURPOSE DPDT 5A 12VManufacturer: Omron Automation and Safety
Categories: Power Relays, Over 2 Amps
Quality Control: Learn More
General Purpose Relay DPDT (2 Form C) 12VAC Coil Socketable
Additional Information
Series: MKKRoHS Status: Request inventory verificationManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Mounting Type | Socketable |
| Coil Voltage | 12VAC |
| Operating Temperature | -10°C ~ 40°C |
| Termination Style | Plug In, 11 Pin (Octal) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Coil Current | 128 mA |
| Coil Type | Latching, Dual Coil |
| Seal Rating | - |
| Contact Material | Silver (Ag) |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 250VDC - Max |
| Must Release Voltage | - |
| Must Operate Voltage | 9.6 VAC |
| Operate Time | 30 ms |
| Release Time | 30 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | 1100VA, 72W |
