G6D-F4PU DC24
RELAY GEN PURPOSE SPST 5A 24VManufacturer: Omron Automation and Safety
Categories: Power Relays, Over 2 Amps
Quality Control: Learn More
General Purpose Relay SPST-NO (1 Form A) x 4 24VDC Coil DIN Rail
Additional Information
Series: G6D-F4PURoHS Status: ROHS3 CompliantManufacturer Lead Time: 23 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Diode, Lighted Indicator, Socket Included |
| Packaging | Bulk |
| Mounting Type | DIN Rail |
| Coil Voltage | 24VDC |
| Operating Temperature | -25°C ~ 55°C |
| Termination Style | Spring Terminal |
| Approval Agency | CSA, UR, VDE |
| Relay Type | General Purpose |
| Coil Current | 10.5 mA |
| Coil Type | Non Latching |
| Seal Rating | - |
| Contact Material | - |
| Contact Form | SPST-NO (1 Form A) x 4 |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 30VDC - Max |
| Must Release Voltage | 2.4 VDC |
| Must Operate Voltage | 16.8 VDC |
| Operate Time | 10 ms |
| Release Time | 10 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | 1250VA, 150W |
