SC28L201A1DGG,118
IC UART W/FIFO 48-TSSOPManufacturer: NXP USA Inc.
Categories: UARTs (Universal Asynchronous Receiver Transmitter)
Quality Control: Learn More
NXP USA Inc. Impact Series SC28L201A1DGG-118 is a single-channel UART IC supporting RS485 protocol. This device features a 256-byte FIFO buffer for efficient data handling. It operates with a dual voltage supply of 3.3V and 5V, and offers a maximum data rate of 3.125Mbps. Key functionalities include configurable GPIO, an internal oscillator, and a timer/counter. Auto flow control and false start bit detection are integrated, along with modem control capabilities. The SC28L201A1DGG-118 is supplied in a 48-TSSOP package suitable for surface mounting, delivered on tape and reel. This component is commonly utilized in industrial automation, networking, and telecommunications applications.
Additional Information
Series: ImpactRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Configurable GPIO, Internal Oscillator, Timer/Counter |
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-TFSOP (0.240"", 6.10mm Width) |
| Number of Channels | 1, UART |
| Mounting Type | Surface Mount |
| Voltage - Supply | 3.3V, 5V |
| FIFO's | 256 Byte |
| Protocol | RS485 |
| Data Rate (Max) | 3.125Mbps |
| Supplier Device Package | 48-TSSOP |
| With Auto Flow Control | Yes |
| With IrDA Encoder/Decoder | - |
| With False Start Bit Detection | Yes |
| With Modem Control | Yes |
| Grade | - |
| Qualification | - |
