CBTL02042BBQ,115
IC MUX/DEMUX 2:1 PCI 20DHVQFNManufacturer: NXP USA Inc.
Categories: Special Purpose
Quality Control: Learn More
NXP USA Inc. CBTL02042BBQ-115 is a 2-channel, 2:1 multiplexer/demultiplexer switch IC. This device supports high-speed serial data transmission with a -3dB bandwidth of 7GHz, making it suitable for DisplayPort, PCIe, and USB interfaces. It features bi-directional operation and can also support SATA signaling. The CBTL02042BBQ-115 is housed in a 20-DHVQFN (4.5x2.5) package and is designed for surface mounting. It operates from a single 3V to 3.6V supply and has an on-state resistance typically of 6 Ohms. The operating temperature range is -40°C to 85°C. This component is commonly utilized in consumer electronics and computing applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Bi-Directional, SATA |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | DisplayPort, PCIe, USB |
| On-State Resistance (Max) | 6Ohm (Typ) |
| -3db Bandwidth | 7GHz |
| Supplier Device Package | 20-DHVQFN (4.5x2.5) |
| Voltage - Supply, Single (V+) | 3V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Channels | 2 |
