NX3008NBKMB315
NOW NEXPERIA NX3008NBKMB SMALL SManufacturer: NXP USA Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 30 V 530mA (Ta) 360mW (Ta), 2.7W (Tc) Surface Mount DFN1006B-3
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SC-101, SOT-883 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 530mA (Ta) |
| Rds On (Max) @ Id, Vgs | 1.4Ohm @ 350mA, 4.5V |
| FET Feature | - |
| Power Dissipation (Max) | 360mW (Ta), 2.7W (Tc) |
| Vgs(th) (Max) @ Id | 1.1V @ 250µA |
| Supplier Device Package | DFN1006B-3 |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4.5V |
| Vgs (Max) | ±8V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 0.68 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 50 pF @ 15 V |
