1N4148,143
DIODE GEN PURP 100V 200MA ALF2Manufacturer: NXP USA Inc.
Categories: Single Diodes
Quality Control: Learn More
NXP USA Inc. offers the 1N4148-143, a general-purpose diode designed for a wide range of applications. This component features a maximum DC reverse voltage of 100V and an average rectified forward current of 200mA. Its forward voltage drop is rated at 1V maximum at 10mA. With a low reverse leakage current of 25 nA at 20V and a fast reverse recovery time of 4ns, this small-signal diode is suitable for high-speed switching. The capacitance at 0V and 1MHz is 4pF. The 1N4148-143 is presented in a through-hole DO-204AH, DO-35, Axial package, supplied on cut tape (CT). It operates across a wide temperature range, with a maximum junction temperature of 200°C. This component finds utility in various industrial and consumer electronics, including power supplies and signal processing circuits.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | DO-204AH, DO-35, Axial |
| Mounting Type | Through Hole |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 4pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 200mA |
| Supplier Device Package | ALF2 |
| Operating Temperature - Junction | 200°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 10 mA |
| Current - Reverse Leakage @ Vr | 25 nA @ 20 V |
