MC13214R2
IC RF TXRX+MCU 802.15.4 71LGAManufacturer: NXP USA Inc.
Categories: RF Transceiver ICs
Quality Control: Learn More
NXP USA Inc. MC13214R2 is an RF transceiver IC with an integrated microcontroller, supporting the IEEE 802.15.4 standard. This device operates in the 2.4GHz ISM band, utilizing O-QPSK modulation for data rates up to 250kbps. It features a transmit power of 0dBm and a receive sensitivity of -92dBm. The MC13214R2 is equipped with 60kB of Flash memory and 4kB of RAM, alongside 38 GPIO pins and serial interfaces including I2C and SPI. Designed for surface mounting, it is housed in a 71-VFLGA exposed pad package. Typical applications include wireless sensor networks, smart home automation, and industrial control systems. The component operates within a voltage supply range of 2V to 3.4V and has an operating temperature range of -40°C to 85°C, with a receiving current of 37mA and a transmitting current of 30mA.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 71-VFLGA Exposed Pad |
| Sensitivity | -92dBm |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz |
| Memory Size | 60kB Flash, 4kB RAM |
| Type | TxRx + MCU |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2V ~ 3.4V |
| Power - Output | 0dBm |
| Protocol | Zigbee® |
| Current - Receiving | 37mA |
| Data Rate (Max) | 250kbps |
| Current - Transmitting | 30mA |
| Supplier Device Package | 71-LGA (9x9) |
| GPIO | 38 |
| Modulation | O-QPSK |
| RF Family/Standard | 802.15.4 |
| Serial Interfaces | I2C, SPI |
| Programmable | Not Verified |
