MC13201FC
IC RF TXRX 802.15.4 32HVQFNManufacturer: NXP USA Inc.
Categories: RF Transceiver ICs
Quality Control: Learn More
The NXP USA Inc. MC13201FC is a 2.4GHz RF transceiver IC designed for 802.15.4 and General ISM applications. This transmit/receive component operates within the >1GHz frequency band and supports DSSS and O-QPSK modulation with a maximum data rate of 250kbps. Featuring a 32-HVQFN (5x5) package with an exposed pad for surface mounting, it offers a transmit power of 4dBm and a receive sensitivity of -91dBm. The device draws 30mA during transmission and 37mA during reception, with a supply voltage range of 2V to 3.4V. It includes 7 GPIO pins and utilizes an SPI serial interface for communication. Operating temperature ranges from -40°C to 85°C. This component is utilized in various industrial and consumer electronics applications requiring robust wireless connectivity.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-VFQFN Exposed Pad |
| Sensitivity | -91dBm |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz |
| Memory Size | - |
| Type | TxRx Only |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2V ~ 3.4V |
| Power - Output | 4dBm |
| Protocol | - |
| Current - Receiving | 37mA |
| Data Rate (Max) | 250kbps |
| Current - Transmitting | 30mA |
| Supplier Device Package | 32-HVQFN (5x5) |
| GPIO | 7 |
| Modulation | DSSS, O-QPSK |
| RF Family/Standard | 802.15.4, General ISM > 1GHz |
| Serial Interfaces | SPI |
| Programmable | Not Verified |
Request a Quote
