MC33596FCAER2
RF RX FSK/OOK 304/315/426 32QFNManufacturer: NXP USA Inc.
Categories: RF Receivers
Quality Control: Learn More
NXP USA Inc. MC33596FCAER2 is a versatile RF receiver designed for FSK and OOK modulation schemes. This component operates across multiple frequency bands, including 304MHz, 315MHz, 426MHz, 434MHz, 868MHz, and 915MHz, offering broad application flexibility. It achieves a sensitivity of -104dBm and supports data rates up to 22.4kBaud. The MC33596FCAER2 is housed in a 32-QFN-EP (5x5) package, suitable for PCB surface mounting. Its typical applications include general data transfer, and it is commonly found in automotive, consumer electronics, and industrial control systems. The device operates with supply voltages ranging from 2.7V to 3.6V and 4.5V to 5.5V, with a receiving current draw of 10.3mA. The operating temperature range is -20°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: Not For New DesignsPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 32-VFQFN Exposed Pad |
| Sensitivity | -104dBm |
| Mounting Type | Surface Mount |
| Frequency | 304MHz, 315MHz, 426MHz, 434MHz, 868MHz, 915MHz |
| Memory Size | - |
| Modulation or Protocol | FSK, OOK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -20°C ~ 85°C |
| Voltage - Supply | 2.7V ~ 3.6V, 4.5V ~ 5.5V |
| Applications | General Data Transfer |
| Current - Receiving | 10.3mA |
| Data Rate (Max) | 22.4kBaud |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 32-QFN-EP (5x5) |
