SA602AD/01,112
IC MIXER 500MHZ UP CONVRT 8SOManufacturer: NXP USA Inc.
Categories: RF Mixers
Quality Control: Learn More
NXP SA602AD-01-112 is a highly integrated RF mixer IC designed for upconversion applications. This single-mixer device operates across Cellular, HF, UHF, and VHF frequency bands, featuring a maximum input frequency of 500MHz. The SA602 series component delivers a typical conversion gain of 17dB and a noise figure of 5dB, crucial for maintaining signal integrity in demanding RF front-ends. It operates from a single supply voltage ranging from 4.5V to 8V, with a low current consumption of 2.4mA. The SA602AD-01-112 is housed in an 8-SOIC package, suitable for surface mount assembly. This component is widely utilized in radio communication systems, including broadcast receivers and portable transceivers.
Additional Information
Series: SA602RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 500MHz |
| RF Type | Cellular, HF, UHF, VHF |
| Voltage - Supply | 4.5V ~ 8V |
| Gain | 17dB |
| Current - Supply | 2.4mA |
| Secondary Attributes | Up Converter |
| Noise Figure | 5dB |
| Number of Mixers | 1 |
| Supplier Device Package | 8-SO |
