MRFE6VP5300GNR1
RF MOSFET LDMOS 50V TO270-4Manufacturer: NXP USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
NXP USA Inc. MRFE6VP5300GNR1 is a high-power RF MOSFET utilizing LDMOS technology, delivering 300W of output power across a broad frequency range from 1.8MHz to 600MHz. This dual-configuration device offers a typical small-signal gain of 27dB and operates with a test voltage of 50V, while its rated voltage is 133V. The component is supplied in a TO-270 WB-4 Gull package for surface mounting and is available on tape and reel (TR). Its robust performance characteristics make it suitable for demanding applications in industrial, medical, and aerospace industries.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-270BB |
| Current Rating (Amps) | - |
| Mounting Type | Surface Mount |
| Frequency | 1.8MHz ~ 600MHz |
| Configuration | Dual |
| Power - Output | 300W |
| Gain | 27dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | TO-270 WB-4 Gull |
| Voltage - Rated | 133 V |
| Voltage - Test | 50 V |
| Current - Test | 100 mA |
