MRF8P9300HR6
RF MOSFET LDMOS 28V NI1230Manufacturer: NXP USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
The NXP USA Inc. MRF8P9300HR6 is a high-power LDMOS RF MOSFET designed for demanding applications. This dual-configuration device operates at 960MHz, delivering 100W of output power with a typical gain of 19.4dB. Tested at 28V, it features a 2.4A test current and is built using advanced LDMOS technology for superior performance and reliability. The NI-1230 package, supplied on tape and reel, is suitable for chassis mounting. This component is widely utilized in base station infrastructure and other high-frequency power amplifier systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | NI-1230 |
| Current Rating (Amps) | - |
| Mounting Type | Chassis Mount |
| Frequency | 960MHz |
| Configuration | Dual |
| Power - Output | 100W |
| Gain | 19.4dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | NI-1230 |
| Voltage - Rated | 70 V |
| Voltage - Test | 28 V |
| Current - Test | 2.4 A |
