MRF6V4300NR1
RF MOSFET LDMOS 50V TO270-4Manufacturer: NXP USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
NXP USA Inc. MRF6V4300NR1 is an RF power MOSFET utilizing LDMOS technology. This device is rated for a drain-source voltage of 110V, with a test voltage of 50V. It delivers a high output power of 300W at a frequency of 450MHz, featuring a gain of 22dB. The current rating is specified at 900mA for testing. Encased in a TO-270 WB-4 package, it is supplied on Tape & Reel (TR). This component is suitable for applications in base station infrastructure and other demanding RF power amplification systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-270AB |
| Current Rating (Amps) | - |
| Mounting Type | Surface Mount |
| Frequency | 450MHz |
| Power - Output | 300W |
| Gain | 22dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | TO-270 WB-4 |
| Voltage - Rated | 110 V |
| Voltage - Test | 50 V |
| Current - Test | 900 mA |
Request a Quote
