BF1212R,215
RF MOSFET 5V SOT143RManufacturer: NXP USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
NXP USA Inc. BF1212R-215 is a surface mount RF MOSFET in a SOT-143R package. This N-channel dual-gate device operates at a rated voltage of 6V and is tested at 5V. It features a typical drain current of 12mA and a continuous current rating of 30mA. Optimized for RF applications, the BF1212R-215 exhibits a gain of 30dB at 400MHz, with a noise figure of 0.9dB. The component is supplied on a tape and reel for efficient automated assembly. This device is commonly utilized in wireless communication systems and consumer electronics requiring high-frequency switching and amplification.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-143R |
| Current Rating (Amps) | 30mA |
| Mounting Type | Surface Mount |
| Frequency | 400MHz |
| Configuration | N-Channel Dual Gate |
| Power - Output | - |
| Gain | 30dB |
| Technology | MOSFET (Metal Oxide) |
| Noise Figure | 0.9dB |
| Supplier Device Package | SOT-143R |
| Voltage - Rated | 6 V |
| Voltage - Test | 5 V |
| Current - Test | 12 mA |
