MML09231HT1
IC RF AMP GSM 700MHZ-1.4GHZ 8DFNManufacturer: NXP USA Inc.
Categories: RF Amplifiers
Quality Control: Learn More
NXP USA Inc. MML09231HT1 is a high-performance RF amplifier designed for demanding wireless applications. This component operates across a frequency range of 700MHz to 1.4GHz, supporting key cellular standards including GSM, LTE, and W-CDMA. Delivering a gain of 17.2dB at a test frequency of 900MHz, it offers a low noise figure of 0.36dB and a P1dB output power of 24.5dBm. The device is supplied in a compact 8-DFN (2x2) surface-mount package, featuring an exposed pad for enhanced thermal management. With a typical supply current of 55mA and a supply voltage of 5V, the MML09231HT1 is suitable for integration into base stations, mobile devices, and other wireless infrastructure where efficient amplification and signal integrity are critical. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 700MHz ~ 1.4GHz |
| RF Type | GSM, LTE, W-CDMA |
| Voltage - Supply | 5V |
| Gain | 17.2dB |
| Current - Supply | 55mA |
| Noise Figure | 0.36dB |
| P1dB | 24.5dBm |
| Test Frequency | 900MHz |
| Supplier Device Package | 8-DFN (2x2) |
