MPXV5010DP
SENSOR 1.45PSID 0.13"" 4.7V 8SOPManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
The NXP USA Inc. MPXV5010DP is a highly integrated silicon piezoresistive pressure sensor designed for differential pressure measurement. This component, part of the MPXV5010 series, offers an analog voltage output ranging from 0.2 V to 4.7 V, proportional to the applied differential pressure. It features a 1.45 PSI (10 kPa) operating pressure range and a maximum pressure rating of 5.8 PSI (40 kPa). The sensor is temperature compensated and exhibits an accuracy of ±5%.
The MPXV5010DP is housed in an 8-BSOP package with dual, barbed ports designed for a 0.13" (3.3mm) tube. Its surface mount configuration and gull wing termination facilitate integration into various electronic systems. This device is commonly utilized in applications requiring precise pressure monitoring within the automotive, industrial, and medical sectors. The operating temperature range is -40°C to 125°C, with a supply voltage of 4.75V to 5.25V.
Additional Information
Series: MPXV5010RoHS Status: ROHS3 CompliantManufacturer Lead Time: 52 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 8-BSOP (0.475"", 12.06mm Width) Dual Ports, Same Side |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 0.2 V ~ 4.7 V |
| Operating Pressure | 1.45PSI (10kPa) |
| Pressure Type | Differential |
| Accuracy | ±5% |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | Gull Wing |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.13"" (3.3mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | 8-SOP |
| Port Style | Barbed |
| Maximum Pressure | 5.8PSI (40kPa) |
