MPXM2051GST1
SENSOR 7.25PSIG 0.12"" .04V 5MPAKManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
The NXP USA Inc. MPXM2051G series pressure sensor, part number MPXM2051GST1, is a vented gauge sensor with a ±0.3% accuracy. This surface mountable component features a Wheatstone bridge output providing 0 mV to 40 mV when supplied with 10V. Designed for a 50kPa (7.25PSI) operating pressure, it has a maximum pressure rating of 200kPa (29.01PSI). The sensor has a 2.97mm (0.12") tube port and operates within a -40°C to 125°C temperature range. It is temperature compensated and packaged in a 5-MPAK module with gull wing termination, supplied on tape and reel. This component is suitable for board mount applications in various industries including automotive and industrial automation.
Additional Information
Series: MPXM2051GRoHS Status: ROHS3 CompliantManufacturer Lead Time: 39 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-SMD Module, Top Port |
| Output Type | Wheatstone Bridge |
| Mounting Type | Surface Mount |
| Output | 0 mV ~ 40 mV (10V) |
| Operating Pressure | 7.25PSI (50kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±0.3% |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | Gull Wing |
| Voltage - Supply | 10V ~ 16V |
| Port Size | Male - 0.12"" (2.97mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | 5-MPAK |
| Port Style | Barbless |
| Maximum Pressure | 29.01PSI (200kPa) |
