MPX5050DP
SENSOR 7.25PSID 0.19"" 4.7VManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
The NXP USA Inc. MPX5050 series pressure sensor, part number MPX5050DP, is a differential pressure transducer designed for board mounting. This component offers an analog voltage output ranging from 0.2V to 4.7V, with a supply voltage requirement of 4.75V to 5.25V. It features temperature compensation for enhanced performance across its operating temperature range of -40°C to 125°C. The sensor is specified for an operating pressure of 7.25 PSI (50kPa) differentially, with a maximum pressure capability of 29.01 PSI (200kPa). The dual port design utilizes barbed, male connections with a 0.19-inch (4.93mm) tube size. Accuracy is rated at ±2.5%. This sensor is commonly utilized in automotive, industrial automation, and medical equipment applications. The device is supplied in a 6-SIP module package.
Additional Information
Series: MPX5050RoHS Status: ROHS3 CompliantManufacturer Lead Time: 52 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 6-SIP Module |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.2 V ~ 4.7 V |
| Operating Pressure | 7.25PSI (50kPa) |
| Pressure Type | Differential |
| Accuracy | ±2.5% |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.19"" (4.93mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | 29.01PSI (200kPa) |
