MPX5010GP
SENSOR 1.45PSIG 0.19"" 4.7VManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
NXP USA Inc. MPX5010GP is a vented gauge pressure sensor designed for board mounting applications. This analog output sensor operates within a supply voltage range of 4.75V to 5.25V, providing a linear output voltage from 0.2V to 4.7V. Featuring temperature compensation and ±5% accuracy, it is specified for an operating pressure of 1.45 PSI (10 kPa) and a maximum pressure of 5.8 PSI (40 kPa). The MPX5010 series sensor utilizes a 0.19" (4.93mm) barbed port for connection. Its 6-SIP module package with PC pin termination facilitates through-hole mounting. This component is well-suited for applications in industrial automation and automotive systems where precise pressure monitoring is critical.
Additional Information
Series: MPX5010RoHS Status: ROHS3 CompliantManufacturer Lead Time: 52 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 6-SIP Module |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.2 V ~ 4.7 V |
| Operating Pressure | 1.45PSI (10kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±5% |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.19"" (4.93mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | 5.8PSI (40kPa) |
