MPX2202DP
SENSOR 29.01PSID 0.19"" .04VManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
NXP USA Inc. MPX2202DP is a temperature-compensated differential pressure sensor. This 4-SIP module utilizes a Wheatstone bridge output configuration, providing a voltage range of 0 mV to 40 mV, scalable to a 10V supply. Designed for through-hole mounting, it features dual barbed ports with a 0.19-inch (4.93mm) tube size for direct connection. The sensor operates within an ambient temperature range of -40°C to 125°C, with a nominal operating pressure of 29.01 PSI (200 kPa) and a maximum pressure rating of 58.02 PSI (400 kPa). This component is suitable for applications requiring precise pressure monitoring in industrial automation and automotive systems.
Additional Information
Series: MPX2202RoHS Status: ROHS3 CompliantManufacturer Lead Time: 39 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 4-SIP Module |
| Output Type | Wheatstone Bridge |
| Mounting Type | Through Hole |
| Output | 0 mV ~ 40 mV (10V) |
| Operating Pressure | 29.01PSI (200kPa) |
| Pressure Type | Differential |
| Accuracy | - |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | PC Pin |
| Voltage - Supply | 10V ~ 16V |
| Port Size | Male - 0.19"" (4.93mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | 58.02PSI (400kPa) |
