MPVZ5004G6T1
SENSOR 0.57PSIG 4.9VManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Pressure Sensor 0.57PSI (3.92kPa) Vented Gauge 1 V ~ 4.9 V 8-SMD Module
Additional Information
Series: MPVZ5004GRoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD Module |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 1 V ~ 4.9 V |
| Operating Pressure | 0.57PSI (3.92kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±6.25% |
| Operating Temperature | 0°C ~ 85°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | - |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | No Port |
| Maximum Pressure | 2.32PSI (16kPa) |
