MP3V5004GVP
SENSOR 0.57PSIG 0.13"" 3V 8SOPManufacturer: NXP USA Inc.
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
NXP USA Inc. MP3V5004 series analog pressure sensor, part number MP3V5004GVP. This vented gauge sensor measures pressure up to 2.32 PSI (16 kPa) with an operating pressure of 0.57 PSI (3.92 kPa). It features temperature compensation and offers an analog voltage output ranging from 0.6 V to 3 V, supplied by a 2.7 V to 3.3 V source. The 8-SOP package with SMD termination facilitates surface mounting. The sensor includes a 0.13-inch (3.17mm) barbed port for tube connection. Accuracy is specified at ±2.5%. This component is utilized in board mount applications across various industries requiring precise pressure monitoring.
Additional Information
Series: MP3V5004RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 8-SMD Module |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 0.6 V ~ 3 V |
| Operating Pressure | 0.57PSI (3.92kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2.5% |
| Operating Temperature | 0°C ~ 85°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 2.7V ~ 3.3V |
| Port Size | Male - 0.13"" (3.17mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | 8-SOP |
| Port Style | Barbed |
| Maximum Pressure | 2.32PSI (16kPa) |
