MCZ33999EKR2
IC PWR SWITCH N-CH 1:16 54SOICManufacturer: NXP USA Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
NXP USA Inc. MCZ33999EKR2 is a 1:16 low-side N-channel power switch/driver with a maximum output current of 900mA per channel. This device features robust fault protection including fixed current limiting, open load detection, over-temperature shutdown, and over-voltage protection. Its capabilities extend to PWM input for precise control and SPI interface for communication. Designed for surface mounting, it is housed in a 54-SOIC-EP (54-SSOP) package with an exposed pad for enhanced thermal performance. The MCZ33999EKR2 operates within a load voltage range of 5V to 27V and a supply voltage of 3.1V to 5.5V, with a typical ON-resistance of 550mOhm. This component is suitable for demanding applications in automotive and industrial automation sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | PWM Input |
| Packaging | Tape & Reel (TR) |
| Package / Case | 54-SSOP (0.295"", 7.50mm Width) Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | - |
| Voltage - Load | 5V ~ 27V |
| Voltage - Supply (Vcc/Vdd) | 3.1V ~ 5.5V |
| Current - Output (Max) | 900mA |
| Ratio - Input:Output | 1:16 |
| Supplier Device Package | 54-SOIC-EP |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
