MCZ33999EK
IC PWR SWITCH N-CH 1:16 54SOICManufacturer: NXP USA Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:16 N-Channel 900mA 54-SOIC-EP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | PWM Input |
| Packaging | Tube |
| Package / Case | 54-SSOP (0.295"", 7.50mm Width) Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | - |
| Voltage - Load | 5V ~ 27V |
| Voltage - Supply (Vcc/Vdd) | 3.1V ~ 5.5V |
| Current - Output (Max) | 900mA |
| Ratio - Input:Output | 1:16 |
| Supplier Device Package | 54-SOIC-EP |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
