MCZ33996EKR2
IC PWR SWITCH N-CH 1:16 32SOICManufacturer: NXP USA Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The NXP USA Inc. MCZ33996EKR2 is a 1:16 N-channel intelligent power controller designed for high-side switching applications. This device features 16 independent low-side N-channel MOSFET outputs, each capable of sourcing up to 900mA. Integrated fault protection includes fixed current limiting, open load detection, over-temperature, and over-voltage protection. The MCZ33996EKR2 communicates via an SPI interface for control and diagnostics. With a voltage load range of 5V to 27V and a supply voltage range of 3.1V to 5.5V, it offers a typical on-resistance of 550mOhm. Encased in a 32-SOIC-EP package, this component is suitable for demanding automotive and industrial applications requiring robust power management and protection. Operating temperature range is -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-SSOP (0.295"", 7.50mm Width) Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | - |
| Voltage - Load | 5V ~ 27V |
| Voltage - Supply (Vcc/Vdd) | 3.1V ~ 5.5V |
| Current - Output (Max) | 900mA |
| Ratio - Input:Output | 1:16 |
| Supplier Device Package | 32-SOIC-EP |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
