MCZ33996EK
IC PWR SWITCH N-CH 1:16 32SOICManufacturer: NXP USA Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
NXP USA Inc. MCZ33996EK is a 16-channel N-channel power switch/driver designed for general-purpose applications. It offers an output current of up to 900mA per channel with a low-side output configuration. This device features robust fault protection including fixed current limiting, open load detection, over-temperature protection, and over-voltage protection. The MCZ33996EK operates across a wide supply voltage range of 3.1V to 5.5V and supports load voltages from 5V to 27V. Its SPI interface facilitates control and monitoring of the 1:16 output configuration. The component is housed in a 32-SOIC-EP package with an exposed pad and has a typical Rds On of 550mOhm. It is suitable for demanding environments, operating from -40°C to 150°C (TJ). This power switch is commonly utilized in automotive and industrial automation sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 32-SSOP (0.295"", 7.50mm Width) Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | - |
| Voltage - Load | 5V ~ 27V |
| Voltage - Supply (Vcc/Vdd) | 3.1V ~ 5.5V |
| Current - Output (Max) | 900mA |
| Ratio - Input:Output | 1:16 |
| Supplier Device Package | 32-SOIC-EP |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
