BUK217-50YT,118
IC PWR DRIVER N-CHAN 1:1 SOT426Manufacturer: NXP USA Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
NXP USA Inc. TOPFET™ BUK217-50YT-118 is a high-side N-channel power switch/driver designed for demanding applications. This General Purpose switch features a 1:1 input to output ratio and a low typ. Rds On of 10mOhm, enabling efficient power delivery. With a maximum output current of 10A, it is suitable for robust power management solutions. The device incorporates comprehensive fault protection, including fixed current limiting, over-temperature, and over-voltage protection, along with a status flag for monitoring. Its TO-263-5, D2PAK (4 Leads + Tab) package is designed for surface mounting. This component finds application in automotive and industrial power control systems.
Additional Information
Series: TOPFET™RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-263-5, D2PAK (4 Leads + Tab), TO-263BB |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | 150°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 10mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 5.5V ~ 35V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 10A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | D2PAK |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage |
