MC33932EK
IC MOTOR DRIVER 5V-28V 54SOICManufacturer: NXP USA Inc.
Categories: Motor Drivers, Controllers
Quality Control: Learn More
NXP USA Inc.'s MC33932EK is a CMOS parallel motor driver designed for demanding automotive applications. This fully integrated component integrates control and power stages, delivering up to 5A output current. It features four half-bridge outputs, supporting Brushed DC motors within a 5V to 28V voltage range. The MC33932EK operates efficiently across a wide temperature spectrum from -40°C to 125°C. Its 54-SOIC-EP (Exposed Pad) package facilitates robust surface mounting and thermal management. This device is well-suited for advanced automotive powertrain and chassis control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 54-SSOP (0.295"", 7.50mm Width) Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 5A |
| Interface | Parallel |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 5V ~ 28V |
| Applications | - |
| Technology | CMOS |
| Voltage - Load | 5V ~ 28V |
| Supplier Device Package | 54-SOIC-EP |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | - |
| Grade | Automotive |
