T2081NSN8PTB
IC MPU QORIQ 1.533GHZ 896FCPBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
PowerPC e6500 Microprocessor IC QorIQ T2 4 Core, 64-Bit 1.533GHz 896-FCPBGA (25x25)
Additional Information
Series: QorIQ T2RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 896-BFBGA, FCBGA |
| Mounting Type | Surface Mount |
| Speed | 1.533GHz |
| Operating Temperature | 0°C ~ 105°C (TA) |
| Core Processor | PowerPC e6500 |
| Voltage - I/O | - |
| Supplier Device Package | 896-FCPBGA (25x25) |
| Ethernet | 1Gbps (8), 2.5Gbps (4), 10Gbps (4) |
| USB | USB 2.0 + PHY (2) |
| Number of Cores/Bus Width | 4 Core, 64-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | DDR3, DDR3L |
| Graphics Acceleration | - |
| Display & Interface Controllers | - |
| Security Features | Boot Security, Cryptography, Secure Fusebox, Secure Debug, Tamper Detection, Volatile key Storage |
| SATA | SATA 3Gbps (2) |
