P5021NXN7TMC
IC MPU QORIQ P5 1.8GHZ 1295BGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. P5021NXN7TMC is a 64-bit, dual-core PowerPC e5500 microprocessor from the QorIQ P5 series. This high-performance processor operates at 1.8GHz and is housed in a 1295-FCPBGA (37.5x37.5) package. It features extensive connectivity options including multiple Gigabit and 10 Gigabit Ethernet ports, SATA 3Gbps interfaces, USB 2.0 with PHY, I2C, MMC/SD, PCIe, and UART. The processor supports DDR3 and DDR3L RAM controllers. Designed for demanding applications, this component is suitable for use in networking infrastructure, industrial control systems, and embedded computing platforms. Operating temperature range is -40°C to 105°C (TA).
Additional Information
Series: QorIQ P5RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 1295-BBGA, FCBGA |
| Mounting Type | Surface Mount |
| Speed | 1.8GHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC e5500 |
| Voltage - I/O | 1.0V, 1.1V |
| Supplier Device Package | 1295-FCPBGA (37.5x37.5) |
| Ethernet | 1Gbps (10), 10Gbps (2) |
| USB | USB 2.0 + PHY (2) |
| Number of Cores/Bus Width | 2 Core, 64-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | DDR3, DDR3L |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | SATA 3Gbps (2) |
| Additional Interfaces | I2C, MMC/SD, PCIe, SPI, UART |
