P4040NXE1MMB
IC MPU QORIQ P4 1.5GHZ 1295BGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. P4040NXE1MMB is a QorIQ P4 series PowerPC e500mc microprocessor. This 4-core, 32-bit component operates at 1.5GHz, featuring a 1295-FCPBGA (37.5x37.5) package. Enhanced with a SEC 4.0 security co-processor, it supports advanced cryptographic functions, boot security, and a random number generator. Connectivity includes eight 1Gbps Ethernet ports, two 10Gbps Ethernet ports, two USB 2.0 ports with PHY, DUART, I2C, MMC/SD, and RapidIO interfaces. The P4040NXE1MMB also integrates DDR2 and DDR3 RAM controllers and operates across a temperature range of -40°C to 105°C. This device is well-suited for demanding applications in networking, telecommunications, and industrial automation.
Additional Information
Series: QorIQ P4RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 1295-BBGA, FCBGA |
| Mounting Type | Surface Mount |
| Speed | 1.5GHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC e500mc |
| Voltage - I/O | 1.8V, 2.5V, 3.3V |
| Supplier Device Package | 1295-FCPBGA (37.5x37.5) |
| Ethernet | 1Gbps (8), 10Gbps (2) |
| USB | USB 2.0 + PHY (2) |
| Number of Cores/Bus Width | 4 Core, 32-Bit |
| Co-Processors/DSP | Security; SEC 4.0 |
| RAM Controllers | DDR2, DDR3 |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | Boot Security, Cryptography, Random Number Generator, Secure Fusebox |
| SATA | - |
| Additional Interfaces | DUART, I2C, MMC/SD, RapidIO, SPI |
