MPC862PCVR66B
IC MPU MPC8XX 66MHZ 357BGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MPC8xx series microprocessor, part number MPC862PCVR66B, is a 32-bit, single-core processor operating at 66MHz. This component features a Communications Processor Module (CPM) for enhanced communication tasks. It offers extensive peripheral connectivity including HDLC/SDLC, I2C, IrDA, PCMCIA, SPI, TDM, and UART/USART interfaces. Network capabilities are supported with four 10Mbps Ethernet ports and one 10/100Mbps Ethernet port. The processor includes DRAM controllers and is packaged in a 357-PBGA (25x25) surface-mount configuration. Manufactured by NXP USA Inc., this device is suitable for applications in telecommunications, networking infrastructure, and industrial control systems. It operates within an ambient temperature range of -40°C to 115°C with I/O voltage at 3.3V.
Additional Information
Series: MPC8xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 357-BBGA |
| Mounting Type | Surface Mount |
| Speed | 66MHz |
| Operating Temperature | -40°C ~ 115°C (TA) |
| Core Processor | MPC8xx |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 357-PBGA (25x25) |
| Ethernet | 10Mbps (4), 10/100Mbps (1) |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; CPM |
| RAM Controllers | DRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | HDLC/SDLC, I2C, IrDA, PCMCIA, SPI, TDM, UART/USART |
