MPC8347ECZUAGDB
IC MPU MPC83XX 400MHZ 672LBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MPC8347ECZUAGDB is a 32-bit PowerPC e300 microprocessor from the MPC83xx series. This single-core device operates at 400MHz and is housed in a 672-LBGA (35x35) package for surface mounting. It features extensive connectivity options including dual 10/100/1000Mbps Ethernet ports, two USB 2.0 ports with PHY, DUART, I2C, PCI, and SPI interfaces. The MPC8347ECZUAGDB includes a Security Engine (SEC) co-processor for cryptography and a Random Number Generator for enhanced security features. It supports DDR RAM controllers and operates within a temperature range of -40°C to 105°C (TA). This component is suitable for applications in networking, industrial automation, and telecommunications.
Additional Information
Series: MPC83xxRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 672-LBGA |
| Mounting Type | Surface Mount |
| Speed | 400MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC e300 |
| Voltage - I/O | 2.5V, 3.3V |
| Supplier Device Package | 672-LBGA (35x35) |
| Ethernet | 10/100/1000Mbps (2) |
| USB | USB 2.0 + PHY (2) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Security; SEC |
| RAM Controllers | DDR |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | Cryptography, Random Number Generator |
| SATA | - |
| Additional Interfaces | DUART, I2C, PCI, SPI |
