MPC8347CVVAJDB
IC MPU MPC83XX 533MHZ 672LBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MPC83xx series MPC8347CVVAJDB is a 32-bit PowerPC e300 microprocessor featuring a single core operating at 533MHz. This component is housed in a 672-LBGA (35x35) package and supports surface mounting. It offers extensive connectivity options including dual 10/100/1000Mbps Ethernet ports, two USB 2.0 ports with integrated PHY, DUART, I2C, PCI, and SPI interfaces. The device includes DDR RAM controllers and operates with I/O voltages of 2.5V and 3.3V. Its operating temperature range is -40°C to 105°C (TA). This microprocessor is commonly utilized in networking equipment, industrial control systems, and telecommunications infrastructure.
Additional Information
Series: MPC83xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 672-LBGA |
| Mounting Type | Surface Mount |
| Speed | 533MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC e300 |
| Voltage - I/O | 2.5V, 3.3V |
| Supplier Device Package | 672-LBGA (35x35) |
| Ethernet | 10/100/1000Mbps (2) |
| USB | USB 2.0 + PHY (2) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | DDR |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | DUART, I2C, PCI, SPI |
