MPC8315ECVRADDA
IC MPU MPC83XX 266MHZ 620HBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. MPC83xx Series MPC8315ECVRADDA is a 32-bit PowerPC e300c3 microprocessor featuring a single core operating at 266MHz. This component, packaged in a 620-HBGA (29x29), supports DDR and DDR2 memory controllers and includes two 10/100/1000Mbps Ethernet interfaces, two SATA 3Gbps ports, and one USB 2.0 with PHY. Additional interfaces include DUART, I2C, PCI, and SPI. The device incorporates a Security Engine (SEC 3.3) with cryptography and a Random Number Generator for enhanced security features. Designed for surface mounting, it operates within an ambient temperature range of -40°C to 105°C and supports I/O voltages of 1.8V, 2.5V, and 3.3V. This microprocessor is suitable for applications in networking, industrial automation, and embedded systems.
Additional Information
Series: MPC83xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 620-BBGA Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 266MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC e300c3 |
| Voltage - I/O | 1.8V, 2.5V, 3.3V |
| Supplier Device Package | 620-HBGA (29x29) |
| Ethernet | 10/100/1000Mbps (2) |
| USB | USB 2.0 + PHY (1) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Security; SEC 3.3 |
| RAM Controllers | DDR, DDR2 |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | Cryptography, Random Number Generator |
| SATA | SATA 3Gbps (2) |
| Additional Interfaces | DUART, I2C, PCI, SPI, TDM |
