MPC8280VVUPEA
IC MPU MPC82XX 450MHZ 480TBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MPC8280VVUPEA is a PowerPC G2_LE microprocessor from the MPC82xx series. This 32-bit, single-core processor operates at 450MHz and is housed in a 480-TBGA package. It features a Communications RISC CPM co-processor, supporting high-speed data processing for demanding applications. Connectivity is extensive, including three 10/100Mbps Ethernet interfaces, a USB 2.0 port, and serial interfaces such as I2C, SCC, SMC, SPI, UART, and USART. The device includes DRAM and SDRAM controllers for memory management. With an operating temperature range of 0°C to 105°C, this component is suitable for use in networking equipment, industrial automation, and telecommunications systems.
Additional Information
Series: MPC82xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 480-LBGA Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 450MHz |
| Operating Temperature | 0°C ~ 105°C (TA) |
| Core Processor | PowerPC G2_LE |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 480-TBGA (37.5x37.5) |
| Ethernet | 10/100Mbps (3) |
| USB | USB 2.0 (1) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; RISC CPM |
| RAM Controllers | DRAM, SDRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | I2C, SCC, SMC, SPI, UART, USART |
