MPC8280CVVUPEA
IC MPU MPC82XX 450MHZ 480TBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. MPC8280CVVUPEA is a PowerPC G2_LE microprocessor from the MPC82xx series. This 32-bit, single-core unit operates at 450MHz and is housed in a 480-TBGA (37.5x37.5) package, surface mountable. It features a Communications RISC CPM co-processor and supports DRAM and SDRAM controllers. Connectivity is enhanced with multiple Ethernet ports (10/100Mbps), USB 2.0, I2C, SCC, SMC, SPI, UART, and USART interfaces. This component is designed for demanding applications in telecommunications, networking equipment, and industrial control systems, operating within an ambient temperature range of -40°C to 105°C. The I/O voltage is 3.3V.
Additional Information
Series: MPC82xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 480-LBGA Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 450MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC G2_LE |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 480-TBGA (37.5x37.5) |
| Ethernet | 10/100Mbps (3) |
| USB | USB 2.0 (1) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; RISC CPM |
| RAM Controllers | DRAM, SDRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | I2C, SCC, SMC, SPI, UART, USART |
