MPC8270CVVQLDA
IC MPU MPC82XX 333MHZ 480TBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. MPC8270CVVQLDA is a 32-bit PowerPC G2_LE microprocessor from the MPC82xx series. This component features a single core operating at 333MHz, integrated with a Communications Processor Module (CPM) for enhanced communication tasks. It offers three 10/100Mbps Ethernet interfaces, a USB 2.0 port, and various peripheral interfaces including I2C, SCC, SMC, SPI, UART, and USART. The MPC8270CVVQLDA supports DRAM and SDRAM memory controllers and operates within an industrial temperature range of -40°C to 105°C. Packaged in a 480-TBGA (37.5x37.5), it is suitable for surface mount applications. This microprocessor is commonly utilized in networking infrastructure, telecommunications equipment, and industrial automation systems.
Additional Information
Series: MPC82xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 480-LBGA Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 333MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC G2_LE |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 480-TBGA (37.5x37.5) |
| Ethernet | 10/100Mbps (3) |
| USB | USB 2.0 (1) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; RISC CPM |
| RAM Controllers | DRAM, SDRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | I2C, SCC, SMC, SPI, UART, USART |
