MPC8245LVV266D
IC MPU MPC82XX 266MHZ 352TBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MPC8245LVV266D is a PowerPC 603e microprocessor, part of the MPC82xx series. This 32-bit, single-core processor operates at 266MHz and is housed in a 352-pin TBGA (35x35) package, designed for surface mounting. It features a voltage for I/O of 3.3V and supports SDRAM controllers. Additional interfaces include I2C, I²O, PCI, and UART. This component is utilized in industrial automation, telecommunications, and embedded control systems. The operating temperature range for this device is 0°C to 105°C (TA).
Additional Information
Series: MPC82xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 352-LBGA |
| Mounting Type | Surface Mount |
| Speed | 266MHz |
| Operating Temperature | 0°C ~ 105°C (TA) |
| Core Processor | PowerPC 603e |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 352-TBGA (35x35) |
| Ethernet | - |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | SDRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | I2C, I²O, PCI, UART |
