MPC7410THX450NE
IC MPU MPC74XX 450MHZ 360CBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. MPC7410THX450NE, a PowerPC G4 microprocessor from the MPC74xx series, offers a 450MHz clock speed with a single 32-bit core. This component features a 360-CBGA (25x25) surface mount package. The I/O voltage range is configurable across 1.8V, 2.5V, and 3.3V. Operating within an ambient temperature range of -40°C to 105°C, the MPC7410THX450NE is a robust solution for applications in embedded systems, networking infrastructure, and industrial automation.
Additional Information
Series: MPC74xxRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 360-BCBGA, FCCBGA |
| Mounting Type | Surface Mount |
| Speed | 450MHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC G4 |
| Voltage - I/O | 1.8V, 2.5V, 3.3V |
| Supplier Device Package | 360-CBGA (25x25) |
| Ethernet | - |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | - |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | - |
Request a Quote
