MC7448THX1400ND
IC MPU MPC74XX 1.4GHZ 360FCCBGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. MPC74xx Series microprocessor, part number MC7448THX1400ND. This PowerPC G4 core processor operates at 1.4GHz with a 32-bit bus width. The component features multimedia and SIMD co-processors. It is housed in a 360-FCCBGA (25x25) package, suitable for surface mounting. Operating temperature range is -40°C to 105°C. I/O voltage options include 1.5V, 1.8V, and 2.5V. This device finds application in networking, telecommunications, and industrial automation.
Additional Information
Series: MPC74xxRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 360-BCBGA, FCCBGA |
| Mounting Type | Surface Mount |
| Speed | 1.4GHz |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor | PowerPC G4 |
| Voltage - I/O | 1.5V, 1.8V, 2.5V |
| Supplier Device Package | 360-FCCBGA (25x25) |
| Ethernet | - |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Multimedia; SIMD |
| RAM Controllers | - |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | - |
