MC68EN360AI33L
IC MPU M683XX 33MHZ 240FQFPManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
NXP USA Inc. M683xx Series Microprocessor, part number MC68EN360AI33L. This 32-bit microprocessor features a single CPU32+ core operating at 33MHz. It includes integrated communications co-processors (CPM) for enhanced data handling. Connectivity is provided via Serial Communications Controllers (SCC), Serial Message Controllers (SMC), and SPI interfaces, with a 10Mbps Ethernet port for networking. The MC68EN360AI33L supports DRAM controllers and is housed in a 240-FQFP (32x32) surface mount package. Designed for industrial automation, telecommunications, and embedded control systems, this component operates within an ambient temperature range of 0°C to 70°C. The I/O voltage is specified at 5.0V.
Additional Information
Series: M683xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 240-BFQFP |
| Mounting Type | Surface Mount |
| Speed | 33MHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Core Processor | CPU32+ |
| Voltage - I/O | 5.0V |
| Supplier Device Package | 240-FQFP (32x32) |
| Ethernet | 10Mbps (1) |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; CPM |
| RAM Controllers | DRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | SCC, SMC, SPI |
Request a Quote
