MC68360ZQ25VL
IC MPU M683XX 25MHZ 357BGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. MC68360ZQ25VL is a 32-bit MPU from the M683xx series, featuring a CPU32+ core operating at 25MHz. This surface mount component, supplied in a 357-PBGA (25x25) package, includes a Communications Processor Module (CPM) co-processor, offering dedicated hardware for communication tasks. Integrated peripherals include Serial Communications Controllers (SCC), Serial Messaging Controllers (SMC), and SPI interfaces, alongside a single 10Mbps Ethernet port. The device also incorporates DRAM controllers for memory management. Its robust feature set makes it suitable for applications in telecommunications, industrial automation, and networking equipment. The operating temperature range is 0°C to 70°C.
Additional Information
Series: M683xxRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 357-BBGA |
| Mounting Type | Surface Mount |
| Speed | 25MHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Core Processor | CPU32+ |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 357-PBGA (25x25) |
| Ethernet | 10Mbps (1) |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | Communications; CPM |
| RAM Controllers | DRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | SCC, SMC, SPI |
Request a Quote
