MC68302RC20C
IC MPU M683XX 20MHZ 132PGAManufacturer: NXP USA Inc.
Categories: Microprocessors
Quality Control: Learn More
The NXP USA Inc. M683xx series MC68302RC20C is a microprocessor featuring a single M68000 core operating at 20MHz. This component offers 8/16-bit bus width and includes a RISC Communications Processor Module (CPM) for enhanced communication processing. It supports various interfaces including GCI, IDL, ISDN, NMSI, PCM, and SCPI. The MC68302RC20C integrates DRAM controllers and is housed in a 132-PGA (34.5x34.5) through-hole package. Its operating temperature range is 0°C to 70°C (TA), with an I/O voltage of 5.0V. This device finds application in telecommunications, networking equipment, and industrial control systems.
Additional Information
Series: M683xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 132-BPGA Exposed Pad |
| Mounting Type | Through Hole |
| Speed | 20MHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Core Processor | M68000 |
| Voltage - I/O | 5.0V |
| Supplier Device Package | 132-PGA (34.5x34.5) |
| Ethernet | - |
| USB | - |
| Number of Cores/Bus Width | 1 Core, 8/16-Bit |
| Co-Processors/DSP | Communications; RISC CPM |
| RAM Controllers | DRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | - |
| Security Features | - |
| SATA | - |
| Additional Interfaces | GCI, IDL, ISDN, NMSI, PCM, SCPI |
