SPC5604BAVLQ4
IC MCU 32BIT 512KB FLASH 144LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MPC56xx Qorivva SPC5604BAVLQ4 microcontroller featuring a 32-bit e200z0h single-core processor operating at 48MHz. This component provides 512KB of FLASH program memory and 32KB of internal RAM, complemented by 64KB of EEPROM. It offers extensive connectivity options including CANbus, I2C, LINbus, SCI, and SPI interfaces. The SPC5604BAVLQ4 integrates 36x10-bit Analog-to-Digital converters and supports numerous peripherals such as DMA, POR, PWM, and WDT. With 123 general-purpose I/O pins and a -40°C to 105°C operating temperature range, it is suitable for demanding applications. The component is housed in a 144-LQFP (20x20) surface-mount package and operates from a 3V to 5.5V supply. This device finds application in automotive and industrial control systems.
Additional Information
Series: MPC56xx QorivvaRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 48MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 64K x 8 |
| Core Processor | e200z0h |
| Data Converters | A/D 36x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Connectivity | CANbus, I2C, LINbus, SCI, SPI |
| Peripherals | DMA, POR, PWM, WDT |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 123 |
| Programmable | Not Verified |
