SPC5517EAVMG80
IC MCU 32B 1.5MB FLASH 208MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MPC55xx Qorivva SPC5517EAVMG80 is a 32-bit dual-core microcontroller featuring e200z0 and e200z1 cores operating at 66MHz. This component offers 1.5MB of FLASH program memory and 80KB of RAM, with an internal oscillator and a 4.5V to 5.25V supply voltage. Connectivity options include CANbus, EBI/EMI, I2C, SCI, and SPI. The SPC5517EAVMG80 is equipped with 40 channels of 12-bit Analog-to-Digital conversion, 111 I/O lines, and peripherals such as DMA, POR, PWM, and WDT. It is supplied in a 208-BGA (17x17) surface mount package and operates within a temperature range of -40°C to 105°C (TA). This device is suitable for automotive and industrial applications.
Additional Information
Series: MPC55xx QorivvaRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 208-BGA |
| Mounting Type | Surface Mount |
| Speed | 66MHz |
| Program Memory Size | 1.5MB (1.5M x 8) |
| RAM Size | 80K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | e200z0, e200z1 |
| Data Converters | A/D 40x12b |
| Core Size | 32-Bit Dual-Core |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.25V |
| Connectivity | CANbus, EBI/EMI, I2C, SCI, SPI |
| Peripherals | DMA, POR, PWM, WDT |
| Supplier Device Package | 208-BGA (17x17) |
| Number of I/O | 111 |
| Programmable | Not Verified |
