SP5746CHK0AMMJ6R
IC MCU 32BIT 3MB FLSH 256MAPPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MPC57xx Series microcontroller, part number SP5746CHK0AMMJ6R, features a 32-bit dual-core e200z2 and e200z4 processor architecture operating at 80MHz/160MHz. This device offers 3MB of FLASH program memory and 512KB of RAM. Connectivity options include CANbus, Ethernet, I2C, LINbus, SAI, SPI, and USB with OTG support. The SP5746CHK0AMMJ6R is housed in a 256-MAPPBGA (17x17) package and is suitable for surface mounting. Integrated peripherals include DMA, LVD, POR, and WDT. Data conversion capabilities are provided by 80x10-bit and 64x12-bit ADCs. The operating temperature range is -40°C to 125°C (TA). This component is commonly utilized in automotive and industrial control applications.
Additional Information
Series: MPC57xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 52 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 256-LBGA |
| Mounting Type | Surface Mount |
| Speed | 80MHz/160MHz |
| Program Memory Size | 3MB (3M x 8) |
| RAM Size | 512K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | e200z2, e200z4 |
| Data Converters | A/D 80x10b, 64x12b |
| Core Size | 32-Bit Dual-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Connectivity | CANbus, Ethernet, I2C, LINbus, SAI, SPI, USB, USB OTG |
| Peripherals | DMA, LVD, POR, WDT |
| Supplier Device Package | 256-MAPPBGA (17x17) |
| Number of I/O | 178 |
| Programmable | Not Verified |
