SCF5249LAG133
IC MCU 32BIT ROMLESS 144LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
The NXP USA Inc. MCF524x series microcontroller, part number SCF5249LAG133, features a 32-bit Coldfire V2 single-core processor operating at 133MHz. This ROMless device offers 96KB of RAM and is housed in a 144-LQFP (20x20) surface mount package. Connectivity options include I2C, IDE, Memory Card, SPI, and UART/USART. Peripherals include DMA, I2S, POR, Serial Audio, and WDT. It also incorporates 4x12-bit Analog-to-Digital converters and supports 34 I/O lines. The operating temperature range is 0°C to 70°C (TA), with a supply voltage requirement of 3V to 3.6V. This component is utilized in industrial automation, consumer electronics, and communications infrastructure.
Additional Information
Series: MCF524xRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 133MHz |
| Program Memory Size | - |
| RAM Size | 96K x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | External |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | Coldfire V2 |
| Data Converters | A/D 4x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | I2C, IDE, Memory Card, SPI, UART/USART |
| Peripherals | DMA, I2S, POR, Serial Audio, WDT |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 34 |
| Programmable | Not Verified |
